Submersible cable 3 core

Name: Submersible cable 3 core
Brand: New India Distributors
Price: 105.0 INR
Availability: InStock

Price 105.0 INR/ Meter

Get a Price/Quote

Submersible cable 3 core Specification

Temperature Range
-10C to +70C

Tolerance
5% on overall dimensions

Coating Type
PVC Sheathed

Connection Type
Hard Wired

Bend Radius
Minimum 10 x Outer Diameter

Flexibility
High

Tensile Strength
Up to 12 N/mm (varies by size)

Sealing Type
Waterproof Sheath

Diameter
Each Core: 1.5 sq.mm to 16 sq.mm (typical options)

Product Type
Submersible Cable, 3 Core

Material
PVC Insulated Copper

Connection
Crimped/Clamped

Shape
Round

Standard
IS 694:2010

Surface Treatment
Smooth PVC Finish

Outer Diameter
8.0 mm - 10.2 mm (varies with size)

Section Shape
Circular

Length
Available in 100 meter coils or as required

Thickness
0.6 mm (Insulation)

Color
Black

Usage
Submersible Pump Connections

Rated Pressure
Suitable for Underwater Use (up to 500m Depth)

Material Grade
Electrolytic Grade Copper

Application
Underwater/Submersible Pumps

About Submersible cable 3 core

Submersible cables are available from 2.5 to 10 sq.mm, 3 core flat cables are used for connecting the submersible to the power supply.

3 Core Flat Cables are used for connecting the submersible pump to the power supply. These cables are manufactured with utmost care, adhering to all stringent environmental conditions required for long life of the cable. The 3 cored are insulated with a speciallly formulated PVC compound. The outer sheath is made from a special compound which is impervious to water, oil, grease and toxic chemicals and can withstand adverse climatic changes.

Reliable Performance in Challenging Conditions

Engineered to withstand harsh underwater environments, this 3 core submersible cable provides optimal electrical conductivity and durability. Its flame retardant and chemical-resistant PVC sheath delivers enhanced protection, ensuring long-lasting functionality. These features make it an excellent choice for submersible pump installations requiring dependable operation at depths of up to 500 meters.

Superior Construction and Compliance

Each cable is made with electrolytic grade multi-strand copper cores, insulated with type A PVC, and finished with an ST1 sheath for superior resistance. Designed with a precise 5% tolerance, the perfectly circular sections and smooth PVC finish ensure secure connections and installation ease. The cable meets IS 694:2010 standards, making it a trustworthy and compliant solution for various industrial needs.

FAQ's of Submersible cable 3 core:

Q: How should the submersible cable 3 core be installed for underwater pump connections?

A: The cable should be installed by hard wiring through crimped or clamped connections, ensuring the waterproof sheath is intact. Follow the recommended minimum bend radius of ten times the outer diameter to prevent any damage and refer to professional guidelines for secure underwater installations.

Q: What is the main benefit of using multi-strand copper cores in this cable?

A: Multi-strand copper enhances flexibility and conductivity, making the cable more resistant to breakage and reducing voltage drop over long distances. This ensures stable performance and prolonged lifespan, especially in deep well and submerged conditions.

Q: When is this cable suitable for use with submersible pumps?

A: This cable is ideal for submersible pumps operating at voltages up to 1100 V and depths of up to 500 meters. Its waterproof sheath, oil and chemical resistance, and flame retardancy make it appropriate for year-round operation, even in challenging environments.

Q: Where can I use this 3 core submersible cable besides pump installations?

A: While primarily designed for submersible and underwater pump applications, the cable can also be used in environments requiring waterproof, flexible, and robust cables, such as fountain wiring and underwater lighting, as long as voltage and environmental specs fit.

Q: What process should I follow to determine the correct cable size for my application?

A: To select the appropriate cross section (1.5 sq.mm to 16 sq.mm), refer to the catalogue for the current carrying capacity based on your pump's load. Consider the installation depth, voltage, and required length to ensure safety and efficient functioning.

Q: How does the flame-retardant and chemical-resistant PVC sheath enhance safety?

A: The flame-retardant PVC sheath minimizes fire hazards by limiting the spread of flames, while its chemical resistance protects the cable from oil and chemical exposure, reducing maintenance needs and improving overall safety in submerged settings.
